POWERMAX PRO
PowerMaxPro
Advanced Home Security for the Broadband Era
The Powermax Pro is available in a range of colours such as White, Alluminium & Black.
PowerMax®Pro is an all-in-one wireless home security system that brings an entirely new level of versatility, connectivity and style to the world of home security. It lets homeowners view and control their homes from anywhere via any web browser or mobile phone, delivering ease of use and reliability, in an elegant, contemporary design.
The PowerMaxPro's intelligent, professional grade architecture delivers exceptionally robust performance, starting with a fast and easy installation and setup. With its built-in PSTN communicator and X-10 home control interface, and the ability to add internal GSM/GPRS or Broadband IP communications modules, it offers users and installers outstanding flexibility: homeowners can select the home security system that matches their requirements and budget; and service providers gain the perfect platform for offering web-based security solutions.
Adding the unique internal PowerLink module turns PowerMaxPro into a fully managed web-based security and home control solution. This solution includes real-time camera surveillance and home control, alarm time image verification, mobile phone and email event notifications, and much more. Homeowners can be logged in to the system via any web browser.
Breeze through installation using intuitive menus and voice prompts. Reduce training time and customer support with the icon-based keypad and audio/visual system status notifications.
PowerMaxPro Features:
High-end, modular design
Self contained; no need for external boxes
Multiple optional built-in modules:
Internal PowerLink module enables camera connectivity for real-time viewing and system operation
Internal GSM/GPRS communicator
Internal Broadband IP communicator
Internal RFID (proximity tag) reader
External voice box
Integral X-10 interface for home management – alarms, lights, home appliances control.
Supports up to 3 partitions and multiple common areas (Optional)
Event reporting to: monitoring stations, pagers, SMS messages, e-mail, web applications, mobile phones, landline phones
Two-way PowerCode™ RF system with diversity antenna enables support for Visonic's two-way sirens and two-way keyfobs for instant feedback from the system Internal or external power supply
Elder care application
LCD-based user interface
28 wireless zones with additional 2 hardwired ports, 1 12v hardwired siren port and 1 PGM port for full coverage of connectivity options
Up to 72 hours battery backup
Supports 8 user codes
Full compliance with most international standards including FCC, EN50131 Grade 2 and more
EASY TOUCH PANEL 10
Product Description
•Operate all your lights and appliances, wirelessly with the touch of a finger
•10"/25 cm touch screen for operating all your X-10 modules.
•Make it easier for everyone to operate all your X10 modules
•Fully wireless and easily mounted into or onto the wall.
•Choose the design that suits your interior perfectly!
•You can use your own text, image or photo on the panel and set the location and function of the touch screen buttons yourself.
•Start today with X-10 Home Automation or fit this panel into your existing X-10 system.
•Easy to use and works without a PC.
Applications
•Set up the size and position of buttons on the screen to suit your own requirements
•Buttons can be configured to control the modules you want
•You can set buttons to run a macro allowing you to run a series of events from one press
•All units OFF/ON, All lights OFF/ON, DIM and BRIGHT functions available
•Design your own style of background or use one of the standard ones which are provided
•Ideal for setting mode lighting or controlling zones within your house
MARMITEK X10 INRARED & RF
COMMAND CENTRE
Product Description
Features
A small table top unit which accepts IR signals from a suitable remote control and converts them to X10 commands. It can control up to 16 unit codes and can be set to house codes A to P. There is a keypad on the top of the unit which allows for manual control of ON/OFF, DIM/BRIGHT, ALL LIGHTS ON, ALL UNITS OFF, OFF of up to 8 X10 devices.
Remote controls such as the Easytouch 35 or Philips Pronto RU960 can be used with this unit however any 'learning' remote control can be programed to access the unit provided it has the special home automation codes within it, your remote's instruction manual should tell you this.
Can be controlled wirelessly using an X10 RF signal (e.g. Marmitek RF remote control Easycontrol8 and EasyTouch35, Marmitek wall switch SS13, Marmitek motion detector MS13, etc.)
MARMITEK X10 SC9000
TELEPHONE DIALLER WITH
DIGIMAX SUPPORT
Product Description
Features
Wireless security system - with built-in voice dialler and X10 controller
•Enhanced security with:
- Tamper supervision of all security devices
•Enhanced convenience with:
- ARM/DISARM by telephone, built-in keypad or remote control
- 2 security messages - alarm and system fault
•Enhanced ease of installation:
- Allocate detectors to your choice of zones
- PABX compatible telephone dialler
- Telephone numbers stored in E2
•X10 controller which allows you to control your X10 devices remotely by phone.
Description
The Voice Dialler Security kit is a fully supervised system that gives you the power to protect your home whether you are at home or away. This kit is easily installed (no wires) and allows you to control the level of security at all times.
In protecting your home, your first requirement is to make sure that the burglar doesn't choose your home. The SC9000 Security System has built-in "prevention features" that make a house look lived-in. Sound via X10 plug-in modules to a radio and/or lights can be turned on any time, whether you are at home or away.
Making your home looked lived-in will dissuade most potential burglars; if, however, the burglar is determined to enter your home, the SC9000 Security System using X10 external motion sensors it can trigger more sound, bark the electronic dog and turn on lights as the burglar approaches the house using the appropriate optional X10 devices
In the event that the burglar does break-in, the second requirement is to get him/her out of your house as quickly as possible. If a window or door sensor or motion detector is activated, sirens of 95 dBs will sound and make your house physically uncomfortable for the burglar thus forcing him/her to leave as quickly as possible. A voice dialler system will immediately call a friend or neighbor, playing your pre-recorded message indicating that there is a problem at your residence. A listen-in feature allows the friend or neighbor to hear what is going on inside the home and take appropriate action.
The SC9000 also has the very useful ability of allowing you to control your X10 devices remotely by simply dialing in and then using keystrokes to turn on/off items as required. This can be used to switch lights, appliances or to switch your heating on before you get home.
In protecting yourself, your home and your loved ones, the voice dialler security kit makes life more secure and more relaxed.
X10 MC10 MINI CONTROLLER
Product Description
Overview
Features
•Command up to 8 different X10 receivers
•ON and OFF buttons for four unit codes (switchable to control another 4 units)
•House codes can be set from A to P
•Rocker switch to control DIM and BRIGHT
•ALL LIGHTS ON and ALL UNITS OFF for all receiver units set to the same house code
•LED indicates when X10 signals are being sent
Details
Value priced mini controller allowing control of X10 compatible lamp and appliance modules, wall switches and universal modules.
Made with large anti-slip foot pads for stability making it ideal as a bedside controller. The House code wheel is hidden behind a hinged lid which gives the unit a compact and sleek look.
Specification
•Requires 220/240V AC wall socket outlet
•Controls up to 8 X10 units
•All on & All off facility
•Bright & Dim feature
X10 CM15PRO COMPUTER
INTERFACE & TRANCEIVER
Product Description
The Marmitek CM15Pro computer interface and transceiver offers the user improved control of their X10 modules along with Marmiteks's ActiveHomePro software (which is included), this is a great package for the serious or novice X10 user and provides the following features:-
•This is the Pro-version of the CM11 compare with the CM15pro Click here
•More programming possibilities because of conditional macros. For instance; the simulation of presence is executed only when your alarm is activated.
•With more memory available its possibile to use approximately 1.400 macros/timers steps.
•Ready built X-10 RF transmitter and X-10 transceiver (like the TM13) for specific or all HouseCodes.
•User friendly software for beginners, with numerous extension possibilities for the experienced X-10 user.
•Can be placed out of sight because of the supplied 1 metre power cord.
•Can be used with your iPhone or smart phone to control your X10 devices when your away from your home, read more here.
Whats in the box
•1x CM15Pro Programmable Computer Interface
•1x USB Cable
•1x ActiveHomePro installation CD
•1x Installation guide
•1x 9 Volt 6LR61 alkaline block battery
•1x Metal bracket
•1x Antenna sleeve
Lorem X10 BAYONET LAMP1
Features
Lamp module which fits into a standard bayonet lamp holder. Provides ON and OFF functions and responds to ALL-LIGHTS-ON and ALL-UNITS-OFF X-10 commands.
•Fits into standard bayonet lamp holder.
•No dial required for setting unit address.
•Suitable for use with energy saving bulbs
Please note that this unit does not have any dimming functionality
Installation
Installation
•Remove the light bulb from its socket and insert the LM15 into the light socket.
•Insert a standard light bulb (up to 100W) into the LM15. Energy saving bulbs can be used with this product.
•Turn the lamp switch on if appropriate.
•Set any X-10 controller to the House Code and Unit Code you want want the LM15 to respond to.
•Press the ON button (corresponding to the Unit Code you want the LM15 to respond to) on the X-10 controller three times, at about one second intervals. On the third press, the lamp will turn on signifying that the code has been learnt. To set the code from an IR7243 Infrared Command Centre, press the number three times only.
•To change the code that the LM15 responds to, turn off the power to the unit, turn it back on and repeat the previous step within 30 seconds after applying power.
Specification
Technical Specifications
Supply voltage: 230V +10%/-15% 50Hz
max. 100 W/230V for open shades, max. 60 W/230V for closed shades. Does not contain a dimmer
Dimensions: Length 45, Width 45, Height 95 mm
This product is CE approved for use in the EU
Lorem X10 SCREW-IN LAMP2
Features
•Fits into standard ES screw-in lamp holder.
•No dial required for setting unit address.
•Suitable for use with energy saving bulbs
Lamp module which fits into a standard ES lamp holder. Provides ON and OFF functions and responds to ALL-LIGHTS-ON and ALL-UNITS-OFF X-10 commands.
Please note that this unit does not have any dimming functionality.
Installation
Installation
•Remove the light bulb from its socket and insert the LM15 into the light socket.
•Insert a standard light bulb (up to 100W) into the LM15. Energy saving bulbs can be used with this product.
•Turn the lamp switch on if appropriate.
•Set any X-10 controller to the House Code and Unit Code you want want the LM15 to respond to.
•Press the ON button (corresponding to the Unit Code you want the LM15 to respond to) on the X-10 controller three times, at about one second intervals. On the third press, the lamp will turn on signifying that the code has been learnt. To set the code from an IR7243 Infrared Command Centre, press the number three times only.
•To change the code that the LM15 responds to, turn off the power to the unit, turn it back on and repeat the previous step within 30 seconds after applying power.
Specification
Dimensions
Dimensions: Length 45, Width 45, Height 95 mm
Supply Voltage
Supply voltage: 230V +10%/-15% 50Hz
Switching power: max. 100 W/230V for open shades, max. 60 W/230V for closed shades. Does not contain a dimmer
This product is CE approved for use in the EU
Lorem X10 APPLIANCE MODULE AM12U3
Features
•On/Off function to control an energy saving light, heater, fan, coffee maker, etc.
•Designed to operate with 230V AC loads of up to 500W (incandescent lamps and halogen light) or 230W (motors) or 3600W (resistive loads)
The Marmitek appliance module is a receiver unit that works as a remote controlled switch or relay. You can plug it into any plug socket in the house and control the unit attached to it via X10 commands.
Details
The appliance module can switch incandescent lamps up to 500W, appliances with electric motors up to 230W.
As the X-10 switch is simply inserted into wall sockets like an ordinary plug, there is no installation to be carried out. Just set the wheels on the front to the desired device address (eg. G7) and note this address down.
The load connected to the switch module can still be controlled locally by its own switch, but dont forget to leave the local switch in the "ON" position, as otherwise the load cannot be controlled by an X-10 controller. Switch the load off by remote control. The unit responds to "standard" X-10 commands. ie. All-Units-Off, On and Off.
Specification
Dimensions
Dimensions: Length 122, Width 52, Height 44 mm
This product is CE approved for use in the EU
Technical Specifications
Supply voltage: 230V +-10% 50Hz
Supply current: =< 20mA capacitive
500W (incandescent lamps and halogen light) 230W (motors) 3600W (resistive loads)
Responds to X-10 Key codes: All Units Off, On, Off
Signal sensitivity: 15mVpp min 50mVpp max at 120KHz
Input impedance: => 180Ohms (L-N) at 120KHz
This product is CE approved for use in the EU
Ambient temperature: -10C to +40C (operation), -20C to +70C (storage)
Lorem X10 LAMP MODULE4- 2G
Features
•Latest 2nd generation X10 lamp module with built in noise filter and improved signal sensitivity
•On/Off/dim/bright functions by X10 remote control for control of plug in lighting
•Designed to operate with 230V AC loads of up to 600W
•Includes manual on/off button on the front of the module
Soft start with memory dim setting •LED indication lamp shows status of module
The lamp module unit works as a remote controlled switch or relay. You can plug it into any plug socket in the house and control the light attached to it via X10 commands.
Details
The Lamp Module can switch incandescent lamps up to 600W
As the X-10 appliance module is simply inserted into a wall socket like an ordinary plug and the address code is set electronically using the Mini Controller
The Lamp Module can still be operated locally by its own ON/OFF button or switch the load off/on by remote control. The unit responds to "standard" X-10 commands. ie. All-lights-Off, On and Off, Dim and Bright
Specification
This product is CE approved for use in the EU.
Blue LED X10 Activity/Module Status Light.
Built in noise filter to improve performance
Technical Specifications
Supply voltage: 230V +-10% 50Hz
Standby Power: =<1W
Making capacity: 60W minimum 600W max. (incandescent loads)
High X10 signal sensitivity: 25mV
Soft start and turn off
Memory dim level, switches on to the light level the module was on when switched off
Operating temperature: -10C to +50C (operation)
Lorem X10 DIMMING ACUATOR/INTERFACE
Features
The Marmitek Xanura Home DAIX12 is both a dimming actuator and an interface equipped with a 230 V input. This module must be fitted in junction or distribution boxes and can be used in combination with: Wall sockets, Retractive switches with one or two normally open contacts. The DAIX12 can be used for easy automation of lighting circuits so that they can be switched or dimmed remotely or manually.
•One 230 V input
•25 - 250 W lighting load*
•For incandescent lamps and halogen lighting at 230 V and lowvoltage halogen lighting with wound or leading edge electronic transformer
•A two or three way dimmimg circuit can be automated with only one module
•Can be incorporated in a group command
•Memory mode, switches On to the last used dimming position
•Status retention in the event of the loss and recovery of mains voltage
•Softstart and softdim
•Can be programmed remotely
Lorem X10 SAX4 SWITCH ACTUATOR 16A DIN
Features
With the SAX4 you can control appliances and lights using the Marmitek X-10 system. Ideal for use with garden ponds, light groups, other appliances and in the office.
•Switch for installation on DIN Rail.
•Switches loads up to 3600W.
•Can be remotely switched using regular, momentary timer or delay switches or via the mains using Marmitek X-10 Commands.
•Status indication with LED lamp.
•3A (motors), 16A (resistive loads)
•230V, 50Hz
Lorem X10 DIGIMAX 210 WIRELESS ROOM THERMOSTAT
Features
•Wireless thermostat
•Automatically turn down the heating when you leave the house (with SC9000 controller)
•Control your heating system remotely by phone (with SC9000 controller)
•Can be used with the SC2800 or SC9000 Home Automation controller
A controllable, wireless X10 compatible room thermostat that allows you to control central heating via X10 commands.
The DigiMax 210 can be added as a sensor to the SC2800 or SC9000 (Totalguard) system controllers.
When combined with an SC2800 or SC9000, the DigiMax 210 is the perfect solution for temperature control in a holiday property via the telephone.
An example of a complete heating solution using a DigiMax 210 would be:
•1 x SC9000 system controller
•1 x Digimax 210 thermostat
•1 x Wired Appliance module AM12 (for mains switching of heating pump/circuit) or 1 x Universal Module (for switching a low voltage contact on a heating controller)
The RF DigiMax 210 thermostat does not need any extra wiring and works within 30 meters range of the base unit (SC9000).
It is equiped with a secured RF code which the base unit will learn during the installation process. This code will assure that your heating will only be controlled by your DigiMax 210.
Lorem X10 POWERMAX CONTROLLER
Main Controller for X-10 connection and control from the Visonic Powermax Panel.
Supplied with a plug in 2 metre lead.
Lorem X10 UNIVERSAL MODULE
X10 Universal Module
This module uses isolated contacts to control such low voltage devices as sprinkler systems, curtain controls, garage door openers, and garden lighting. It can be set for momentary or sustained contact closure, and has a built in chime.
Features: Rated a 5 amps at 24v DC
